产品介绍：

The Temperature and Climatic Test Chamber is a compact test system with a high level of performance. It is use to create specific and highly controlled temperature and humidity conditions to simulate a real environmental conditions. The continuos development of the modular system protects your investment for the future. Area of applications are in quality assurance, research and development of components and products such as automotive parts,

semiconductor, Research and development, electronics, photovoltaic, EV batteries,material and so on.

温度试验箱和气候试验箱是具有高性能的紧凑型的测试系统。它用于创建特定的高度受控的温度和湿度条件，以模拟实际的环境条件。模块化系统的持续发展保护了您未来的投资。试验箱应用于质量保证和零部件产品的研发，例如汽车零部件、半导体、研究开发、电子电器、光伏、新能源电池和材料等众多领域。

产品规格：

Standard Technical Data:

标准的技术参数：

• Temperature Range 温度范围: -80 °C, -70 °C, -40 °C,..........+100 °C, +180 °C, +250 °C.

• Heating Rate 升温速率/ Cooling Rate 降温速率: 2 °C/min, 5 °C/min,..........30 °C/min.

• Humidity Range 湿度范围: 10 % to 98 % relative humidity.

Size:

内部容积：

• Standard volume available 可应用的内部容积: 200L, 320L, 600L, 1000L and 1500L.

• Other volumes are available upon customer request.其它尺寸可根据用户需求定制。

Design:

工艺设计：

• The floor assembly, door and bearing parts are made of stainless steel.

• 底板组件，门和门铰链部件均由不锈钢制成。

• Build on a sturdy frame for higher weight loads in the test space.

• 建立在坚固的框架上，以在测试空间中承受更大的重量负载。

• The program control based on CAN bus is integrated into the door and allows many

opportunities to network with a high operating comfort.

• 基于 CAN 总线的程序控制已集成到试验箱门内，并提供了许多以较高的操作舒适度

进行联网的机会。

• Protection of the environment through integrated energy management.

• 通过集成能源管理系统来保护环境。

• C-rails on the side walls for the continuous adjustment of shelves.

• 侧壁上的 C 形导轨，用于连续调整样品架。

Options：

选件备件:

-Wedge implementing 边缘焊接

- Rectangle implementing 矩形设计

- Door window 观察窗

- Deep Drying 深层干燥

- Sound proofing 隔音工艺

- Shelf 样品架

- Solar simulation 光照模拟

- Explosion protection 防爆设计

- Harmful Gases 有害气体

C-rails, shelves, lighting

C 型导轨、样品架、照明

Supporting frame

支撑框架
